Geiwre
Power Connection
1)Related Supply Voltage : 200 V To 240v + 10 %
2)ii Related Supply Frequency :50/60 Hz
3)Line Current Max:2 Amp
4)Power Input Stand By : 10 Watt
5)Power Input Max :400 Watt
6)Power Fuse : 5 Amps
7)Input Mains Voltage : Ful Regulation Range : 208-264 Vac
8) Input Mains Voltage : Operating Range : 170 -264 VacMains Current (Maximum)
9)Mains Current (Maximum) :Idle : 0.040 A Cut : 1.54 A Coag : 0.68 A Bipolar : .54 A Seal : 0.95 A
Daimonions And Weight
Length : 290 mm
Heights : 105 mm
Depth : 260 mm
Weight : 4 kgs
Display : 7 segment LED
Keyboard : Feather touch
Ambient Conditions for Operating
Tempreture : +10 °c To +40 °c
Relative humidity : 15 % - 18 %
Key Features
Body Protected and cardiac protected design.
Fully Microprocessor controlled.
Four CUT modes Pure Cut, Blend 1, Blend 2 and Endocut.Three coagulation Modes Spray, Fulgurate and Desiccate.Three Bipolar modes Soft, Force And Cut.Isolated RF output minimizes the potential of alternate site burns.Standard connectors accept the latest monopolar and bipolar instruments.99 program modes: User settable program mode.Patient Plate monitoring Systems is ultimate safety for retur electrode site burns.HF Leakage current>150mA
Separates Monopolar and Bipolar mode with individual foot-switches.
Electrosurgical Unit Advantages of Ultrasonic Scalpel
CUT MODES
1. PURE CUT :. A high-frequency alternating current yields smooth, rapid cuts that evoke little to no hemostasis. The current stimulates cells to swell and explode. During cutting it is essential to press CUT footswitch before touching the tissue and maintain the spark at the tissue. maximum setting limit is up to 400.
2. BLEND 1-– This is a monopolar Cut mode that is modified to allow for minimal coagulation along the wound edges. Intended uses are for minimally vascularized polyps and areas that can be spot coagulated, post dissection. 75% duty cycle. maximum setting limit is up to 250.
3 . BLEND 2-This is a monopolar Cut mode that is modified to allow for moderate coagulation along the wound edges. Intended uses are for moderately vascular polyps and areas that can be spot coagulated, post dissection. 62.5% duty cycle. maximum setting limit is up to 200
4. ENDOCUT- The mode is used to automatically control cut system to reduce the complication rate of endoscopic sphincterotomy (EST) and serum hyperamylasemia after EST compared to the conventional blended cut mode. maximum setting limit is up to 99
COAG MODES
1. SPRAY- spray output is made for direct coagulation at the tissue with spark. Above spark does not give any cutting effect as its CREST FACTOR is high. maximum setting limit is up to 120
2. FULGURATE- Sparking the tissue to lead to coagulation. There is no tissue-electrode contact; rather, voltage is raised in order to incite a spark between electrodes in order to coagulate the tissue in between. Maximum setting limit is up to 150
3. DESICCATE -Coagulation in which the active electrode is in direct contact with the tissue is referred to as desiccation and is the type of coagulation used in most surgeries It ensures pinpoint desiccation with less destruction of peripheral tissue. Maximum setting limit is up to 150
BIPOLAR MODES
1. SOFT - for highly precise control over coagulation process and privations of carbonization. maximum setting limit is up to 80
2. FORCE - High voltage force coagulation for special purpose when speed is required maximum setting limit is up to 80.
3. CUT- Bipolar CUT technology lets you nearly eliminate excessive current, even during precision cutting in minute tissue structure. maximum setting limit is up to 100
